To Remove

WARNING: This page is about a different car, the 2001 Saab 9-3. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the centre piece at the top by the roof first (fastened with clips).
  2. Remove the window frame trim side pieces by undoing the screw and the clips on each side.
    Fig 1: Removing Window Frame Trim Side Pieces
    G03509900Courtesy of SAAB-SCANIA OF AMERICA, INC.
  3. Remove the holder for the rubber parcel shelf strap.
