Seatbelt Warning Lamp. Open Circuit/Short to Ground

WARNING: This page is about a different car, the 2001 Saab 9-3. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Seatbelt Warning Lamp Circuit Diagram
G03509865Courtesy of SAAB-SCANIA OF AMERICA, INC.
