Technical description: Doors

WARNING: This page is about a different car, the 2001 Saab 9-3. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Door Hinges
G03509362Courtesy of SAAB-SCANIA OF AMERICA, INC.

The hinges in the front and rear doors are lubrication-free, double-sheared and can be dismantled between the body and the door.

The door stop in the front door has a screwed body bracket and the door stop in the rear door has a welded bracket.

The door locks are operated with a key, remote control, door lock button or lock button in the center console. See CENTRAL LOCKING SYSTEM ,
