Crimp connection J76, dashboard harness: Location:

LHD:  Approximately 40 mm from cigarette lighter branching point towards grounding point G41

RHD:  Approximately 130 mm from grounding point G43 branching point towards the radio

Fig 1: Dashboard Harness Crimp Connection Diagram (J65)
G03625813Courtesy of SAAB-SCANIA OF AMERICA, INC.
