Removing Sun Blind For Rear Window

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2023 Porsche Panamera, 2022 Porsche Panamera, 2021 Porsche Panamera, 2020 Porsche Panamera, and 2019 Porsche Panamera. However, it is still accessible from the selected car via links, so may be relevant.
  1. Retract sun blind for rear window.
  2. Only for vehicles with rear shelf (I-no. 3U47):

    Disengage rear shelf -1-  from the rear lid and unclip it at the front.

    G15865225Courtesy of PORSCHE CARS NORTH AMERICA, INC.

    Removing rear shelf

  3. Only for vehicles with roll-up blind (I-no. 3U4):

    Disengage luggage compartment cover -1-  at the rear and retract roll-up blind.

    G15865226Courtesy of PORSCHE CARS NORTH AMERICA, INC.

    Disengaging luggage compartment cover

  4. Pull up lever -2-  and push sun blind for rear window together -arrow-  .
    G15865227Courtesy of PORSCHE CARS NORTH AMERICA, INC.

    Removing luggage compartment cover

  5. Guide out and remove sun blind for rear window.
