Rear Transmission Housing
WARNING: This page is about a different variant/trim than selected.
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Tightening sequence: Transmission housing (rear)
| 2, 9 and 6 |
> Tightening torque 6 Nm (4.5 ftlb.) |
| 1 to 9 |
> Tightening torque 9 Nm (6.5 ftlb.) |
| 1 to 9 |
> Torque angle + 90° |
| 10 to 15 |
> Tightening torque 47 Nm (35 ftlb.) |
