Removing Front Seat Adjustment Switch

WARNING: This page is about a different variant/trim than selected.
  1. Unscrew screws -1-  and remove front seat adjustment switch -2-  .
    G15239946Courtesy of PORSCHE CARS NORTH AMERICA, INC.

    Front seat adjustment switch
