Removing Motor For (Front) Sun Blind
WARNING: This page is about a different variant/trim than selected.
NOTE:
Voltage peaks
- Risk of damage to electrical load or to the control unit
→ Remove the ignition key and switch off load before disconnecting or removing load.
Information
Always comply with the regulations for handling ESD-sensitive components!
- Always wear approved work clothes and shoes when carrying out assembly work.
- Do not remove new parts from ESD (electrostatic discharge) protective packaging until shortly before installation.
- Do not touch electric pins and plug contacts.
- Remove motor for sun blind -3- .
Removing motor for sun blind
- 1.1 Release and unplug electric plug connection -1- .
- 1.2 Unscrew and remove screws -2- .
- 1.3 Remove motor for glass sliding roof -3- .
