Removing Outside Temperature Sensor

NOTIFICATION

Voltage peaks

• Risk of damage to electrical load or to the control unit
  1. → Switch off ignition and keep transmitter key outside of the transmission range (at least 5 m).
  2. → Switch off electrical loads before disconnecting or removing them.

1. Switch off ignition and pull remote control out of ignition lock.
2. Remove outside temperature sensor -2-  .

   Courtesy of PORSCHE CARS NORTH AMERICA, INC.

   Outside temperature sensor

   1. 2.1  Swivel right flap -1-  of the air guide forward.
   2. 2.2  Pull outside temperature sensor -2-  out of the right flap -1-  .
   3. 2.3  Release and unplug electric plug connection -3-  .
