Installation Position

Fig 1: Refrigerant Line Between Evaporator And Dryer (Section From Internal Heat Exchanger Connection Point To Dryer) Components Location

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Installation position

1	Section: Internal heat exchanger connection point to desiccator
2	Section: Internal heat exchanger connection point to evaporator (chiller)
3	Section: Evaporator to expansion valve
4	Section: Evaporator (chiller) to expansion valve 2
