Component Information
Fig 1: Securing Mounting Saddle In Passenger Compartment And Luggage Compartment Components Location
Securing mounting saddle in passenger compartment and luggage compartment
| 1 | Mounting saddle |
| 2 | M8 nuts - for securing mounting saddle in passenger compartment |
| 3 | OTA control unit (Connect - Over The Air) |
| 4 | M8 nut - for securing control unit holder using M8 screw |
| 5 | M8 screws - for securing mounting saddle from the luggage compartment side over the brake booster |
