Home Charging Components

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Mobile Charger

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Mobile Charger Connect

Maximum charging power of 22 kW available [AC] [US variant: 9.6 kW [AC])
Information is forwarded to the customer via a touch display
Network-capable via Powerline Communication [PLC] or WiFi
Use of smart charging functions is fully possible only in combination with the Porsche Home Energy Manager
Compatible with all Porsche hybrid models and electric vehicles

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Home Energy Manager (HEM)

Control component for Porsche Mobile Charger Connect
Real-time monitoring of up to 12 circuits
Energy monitoring of the entire household
Network-capable via Ethernet, Powerline Communication [PLC) and WiFi
Permits use of smart charging functions [ILF) such as:
- Intelligent load management: prevents overloading of the domestic installation
- Cost-optimised charging: charging at off-peak times [if variable electricity prices are available)
- Solar-optimised charging: Support for sustainable charging through the primary use of self-generated electricity [e.g. photovoltaic systems)
- Plug & Charge [home charging)

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Mobile Charger Plus

Maximum charging power of 11 kW available [AC)
Information is provided to the customer by means of status LEDs
Network-capable via Powerline Communication [PLC)
Enables blackout protection in combination with the Porsche Home Energy Manager [prevents overloading of the domestic installation)

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Wall Charger Connect - Not currently available in all markets -

Maximum charging power of 19.6 kW available (AC)
Information is forwarded to the customer via a touch display
Network-capability via Powerline Communication [PLC) or WiFi
The use of smart charging functions is only fully possible in combination with the Porsche Home Energy Manager
Compatible with all Porsche hybrid models and electric vehicles

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Mobile Charger

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Mobile Charger Connect

Maximum charging power of 11 kW available [AC); a 22 kW variant is planned at a later point in time
Information is forwarded to the customer via a touch display
Network-capable via Powerline Communication [PLC) or WiFi
Use of smart charging functions is fully possible only in combination with the Porsche Home Energy Manager
Compatible with all Porsche hybrid models and electric vehicles

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Home Energy Manager (HEM)

Control component for Porsche Mobile Charger Connect
Real-time monitoring of up to 12 circuits
Energy monitoring of the entire household
Network-capable via Ethernet, Powerline Communication [PLC) and WiFi
Permits use of smart charging functions such as:
- Blackout protection: prevents overloading of the domestic installation
- Price-optimised charging: charging at off-peak times [if variable electricity prices are available)
- Own consumption monitoring: support of sustainable charging through use of self-generated power [e.g. from photovoltaic installations)

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Mobile Charger

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Mobile Charger Connect

Maximum charging power of 11 kW available (AC); a 22 kW variant is planned at a later point in time
Information is forwarded to the customer via a touch display
Network-capable via Powerline Communication (PLC) or WiFi
Use of smart charging functions is fully possible only in combination with the Porsche Home Energy Manager
Compatible with all Porsche hybrid models and electric vehicles

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Porsche Home Energy Manager (HEM)

Control component for Porsche Mobile Charger Connect
Real-time monitoring of up to 12 circuits
Energy monitoring of the entire household
Network-capable via Ethernet, Powerline Communication (PLC) and WiFi
Permits use of smart charging functions such as:
- Blackout protection: prevents overloading of the domestic installation
- Price-optimised charging: charging at off-peak times (if variable electricity prices are available)
- Own consumption monitoring: support of sustainable charging through use of self-generated power (e.g. from photovoltaic installations)
