Removing Passenger Compartment Temperature Sensor

  1. Remove passenger compartment temperature sensor -1-  .
    1. 1.1 Release retaining lug -2-  by turning the passenger compartment temperature sensor -1-  in -direction of arrow-  .
    2. 1.2 Remove passenger compartment temperature sensor -1-  .
    G15565479Courtesy of PORSCHE CARS NORTH AMERICA, INC.

    Passenger compartment temperature sensor
