Mounting Engine

WARNING: This page is about a different car, the 2020 Porsche Panamera, 2019 Porsche Panamera, 2018 Porsche Panamera, and 2017 Porsche Panamera. However, it is still accessible from the selected car via links, so may be relevant.

Mount engine on front-axle carrier.
1. 1.1 Lower engine with workshop crane and > 3033 - lifting tackle onto the front-axle carrier and move it into installation position.

Left side of engine:

2.1 Only for all-wheel drive vehicles:
Carefully guide in drive shaft -1- and insert it into the all-wheel final drive console -2- (-arrow- ). Check that the drive shaft is seated securely.

> WM, 404119 REMOVING AND INSTALLING FRONT DRIVE SHAFT

2.2 Fit engine mount -4- on engine carrier -5- .

2.2.1 Fit and tighten screw -3- .

V8 biturbo & V6 Turbo engine: > Initial tightening 70 Nm (52 ftlb.)

V8 biturbo & V6 Turbo engine: > Final tightening + 90°

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Drive shaft and left engine mount (V8 biturbo engine)

Right side of engine:

3.1 Only for all-wheel drive vehicles:
Carefully guide in drive shaft -1- and insert it into the all-wheel final drive -2- (-arrow- ). Check that the drive shaft is seated securely.

> WM, 404119 REMOVING AND INSTALLING FRONT DRIVE SHAFT

3.2 Fit engine mount -4- on engine carrier -5- .

3.2.1 Fit and tighten screw -3- .

V8 biturbo & V6 Turbo engine: > Initial tightening 70 Nm (52 ftlb.)

V8 biturbo & V6 Turbo engine: > Final tightening + 90°

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Drive shaft and right engine mount (V8 biturbo engine shown)
