Technical Values

Location Description Type Basic value Tolerance 1 Tolerance 2
Nut securing rear power windows mechanism to rear door Item 1 Tightening torque 7.5 Nm (5.5 ftlb.)
G15160283Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Rear power windows mechanism
