2X Petrol, Exhaust, Engine-Electric - General 3.0L (Eng Code MDK.Ca) -- 992 - 911 CARRERA (992)
>>
WM, 2X00IN Technical Values
>>
Technical Values - Fuel Supply, Control
>>
Accelerator Pedal
Accelerator Pedal
Location
Description
Type
Basic value
Tolerance
Accelerator pedal to body
internal hexagon round-head bolt, M6 x 18 (replace screw following removal)
Tightening torque
6 Nm (4.5 ftlb.)
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Accelerator pedal
Location
Description
Type
Basic value
Tolerance
Accelerator pedal to body
internal hexagon round-head bolt, M6 x 18 (replace screw following removal)
Tightening torque
6 Nm (4.5 ftlb.)
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Accelerator pedal
