Loudspeakers For Exterior Acoustics
WARNING: This page is about a different variant/trim than selected.
Information
The loudspeakers for exterior acoustics were not installed on every vehicle variant. For allocation, see Parts Information (PET)
Installation overview of loudspeakers for exterior acoustics
Loudspeakers for exterior acoustics
| 1 | Loudspeakers for exterior acoustics |
| 2 | Spring band clamp |
| 3 | Oval-head screws, 5 x 20 -3- > Tightening torque 2 Nm (1.5 ftlb.) + 0.2 Nm (0.1 ftlb.) |
| 4 | Plug connection to the body |
Information
The loudspeakers for exterior acoustics were not installed on every vehicle variant. For allocation, see Parts Information (PET)
Installation overview of loudspeakers for exterior acoustics
Loudspeakers for exterior acoustics
| 1 | Loudspeakers for exterior acoustics |
| 2 | Spring band clamp |
| 3 | Oval-head screws, 5 x 20 -3- > Tightening torque 2 Nm (1.5 ftlb.) + 0.2 Nm (0.1 ftlb.) |
| 4 | Plug connection to the body |
