Installing Boost Pressure Sensor
WARNING: This page is about a different variant/trim than selected.
- Install boost pressure sensor.
Check O-ring and replace it if damaged.
Tighten screw -3-
.
> Tightening torque 3 Nm (2 ftlb.)
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
|
Pressure pipe with boost pressure sensor
