Adjusting Rear-Axle Camber
WARNING: This page is about a different car, the 2024 Porsche 911, 2023 Porsche 911, and 2022 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
- Turn the camber eccentric adjuster -1-
as required after loosening the lock nut -2-
.
Then, tighten lock nut to > Tightening torque 100 Nm (73.8 ftlb.)
.
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
|
Rear-axle camber eccentric
