Installing Front-Axle Support
WARNING: This page is about a different car, the 2024 Porsche 911, 2023 Porsche 911, and 2022 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
- Install front-axle support -1-
.
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
|
Mounting for front-axle support
- 1.1
Engage front-axle support on the front-axle cross member -4-
.
- 1.2
Tighten screws -2-
. > Tightening torque 55 Nm (41 ftlb.)
- 1.3
Tighten screws -3-
. > Tightening torque 55 Nm (41 ftlb.)
