Gap Dimensions Of Rear Window

Location	Description	Type	Basic value	Tolerance
Rear window to side panel, top (H51_0)	Dimension A	Gap dimension	3 mm	+/- 0.7 mm
Courtesy of PORSCHE CARS NORTH AMERICA, INC. Gap dimension of rear window, top
Rear window to side panel, top (H51_0)	Dimension B	Offset	- 4.5 mm	+/- 0.8 mm
Courtesy of PORSCHE CARS NORTH AMERICA, INC. Gap dimension of rear window, top
Rear window to side panel, centre (H51_1)	Dimension A	Gap dimension	3 mm	+/- 0.7 mm
Courtesy of PORSCHE CARS NORTH AMERICA, INC. Gap dimension of rear window, centre
Rear window to side panel, centre (H51_1)	Dimension B	Offset	- 6 mm	+/- 0.8 mm
Courtesy of PORSCHE CARS NORTH AMERICA, INC. Gap dimension of rear window, centre
Rear window to air intake grille	Dimension A	Gap dimension	3 mm	+/- 0.7 mm
Courtesy of PORSCHE CARS NORTH AMERICA, INC. Gap dimension of rear window, bottom
Rear window to air intake grille	Dimension B	Offset	-1 mm	+/- 0.8 mm
Courtesy of PORSCHE CARS NORTH AMERICA, INC. Gap dimension of rear window, bottom
