General Information On The Work Procedure
WARNING: This page is about a different variant/trim than selected.
Information
- The clutch hydraulic system must always be filled or bled using a bleeding device. Furthermore, the bleeder valve must be opened by 1 to 2 turns and the overpressure on the bleeding device must be approx. 1.3 bar (19 psi).
- Once the filling or bleeding process has started, the clutch pedal must be moved (extremely slowly) into the "Pedal fully depressed" position.
- As there is no system pressure, servo kinematic effects will cause the clutch pedal to move forward abruptly. In order to avoid damage, the pedal must be guided by hand.
- In general, a minimum filling time of 90 seconds must be observed. Once this filling period has elapsed, check that no more bubbles appear at the bleeder valve (use a collecting bottle with transparent hose). Only then should you close the bleeder valve.
- Brake fluid must not come into contact with painted surfaces. If this happens, wash the surface immediately with plenty of clean water.
