Assembling Rear Apron

  1. Install cover for towing lug.
G14954369Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  1. 1.1 Hook in safety strap -arrow "A"-  .
  2. 1.2 Fit the cover -arrow "B"-  .
  3. 1.3 Clip in the cover -arrow "C"-  .
