Rear Lid Hinge
WARNING: This page is about a different car, the 2023 Porsche Taycan and 2022 Porsche Taycan. However, it is still accessible from the selected car via links, so may be relevant.
| Location |
Description |
Type |
Basic value |
Tolerance |
| Nuts securing rear lid hinge to rear lid |
Item 2 |
Tightening torque |
20 Nm (15 ftlb.) |
|
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Rear lid hinge |
| Nuts securing rear lid hinge to rear frame |
Item 2 |
Tightening torque |
20 Nm (15 ftlb.) |
|
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Nuts on rear lid hinge |
