Section 2 (Collision - 51 Body Center/Roof/Frame (Y1A))
>>
5165 Transverse Wall Front
>>
WM, 516555 Replacing Front Cross Panel (Firewall Reinforcement)
>>
Installation Position
Installation Position
WARNING:
This page is about a different car, the 2023 Porsche Taycan and 2022 Porsche Taycan. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Front Cross Panel Component Location (Firewall Reinforcement)
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Installation position
