Technical Values

WARNING: This page is about a different car, the 2023 Porsche Taycan and 2022 Porsche Taycan. However, it is still accessible from the selected car via links, so may be relevant.

Location	Des...	Type	Basic val...
Bottom screws securing front wheel housing liner to underbody cover Courtesy of PORSCHE CARS NORTH AMERICA, INC. Screws	Item 1	Tightening torque	2.5 Nm (1.75 ftlb.)
Bottom screws securing front wheel housing liner to front apron Courtesy of PORSCHE CARS NORTH AMERICA, INC. Bottom screws	Item 1	Tightening torque	2.5 Nm (1.75 ftlb.)
Side screws securing front wheel housing liner to body Courtesy of PORSCHE CARS NORTH AMERICA, INC. Screws	Item 1	Tightening torque	2.5 Nm (1.75 ftlb.)
Top screws securing front wheel housing liner to body Courtesy of PORSCHE CARS NORTH AMERICA, INC. Screws	Item 1	Tightening torque	2.5 Nm (1.75 ftlb.)
Bottom screws securing front wheel housing liner to body Courtesy of PORSCHE CARS NORTH AMERICA, INC. Screws	Item 1	Tightening torque	2.5 Nm (1.75 ftlb.)
Bottom nuts securing front wheel housing liner to body Courtesy of PORSCHE CARS NORTH AMERICA, INC. Screws	Item 2	Tightening torque	2.5 Nm (1.75 ftlb.)
