Preliminary Work

WARNING: This page is about a different variant/trim than selected.

Remove engine.
> Removing and reinstalling engine

Only for removing upper chain housing cover on right cylinder bank:
Remove additional coolant pump holder -1- .
1. 2.1 Unscrew screws for additional coolant pump -2- at the holder -1- .
2. 2.2 Unscrew double screw for additional coolant pump holder -3- .
3. 2.3 Remove additional coolant pump holder -1- .

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Additional coolant pump (right cylinder bank)
