Air-Conditioning Compressor Bracket V6
WARNING: This page is about a different variant/trim than selected.
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Air-conditioning compressor bracket
| 1 |
Dust boot |
| 2 |
Screw > Tightening torque 25 Nm (19 ftlb.) |
| 3 |
Tensioning roller |
| 4 |
Screw, M6 x 40/replace > Initial tightening 8 Nm (6 ftlb.)
> Final tightening + 90° |
| 5 |
Air-conditioning compressor bracket |
6
