Removing And Installing Seat Adjustment Switch

  1. Unscrew and remove screws -1-  .
  2. Remove seat adjustment switch -2-  from seat trim panel.
    G16224661Courtesy of PORSCHE CARS NORTH AMERICA, INC.

    Removing seat adjustment switch

  3. Installation is performed in reverse order.
