Subsequent Work

  1. Only for vehicles without PDK:  Install keypad.
    1. 1.1  Connect electric plug connection until the lock engages securely.
    2. 1.2  Clip keypad above the switch console into the centre console. -arrows-
    G16225916Courtesy of PORSCHE CARS NORTH AMERICA, INC.

    Instating keypad

  2. Install centre console cover.

    > 681919 REMOVING AND INSTALLING CENTRE CONSOLE COVER
