Preliminary Work

  1. Remove centre console cover.

    > 681919 REMOVING AND INSTALLING CENTRE CONSOLE COVER

  2. Only for vehicles with PDK:  Remove selector lever knob.

    > 370419 Removing and installing selector knob - section on  "REMOVING "

  3. Only for vehicles without PDK:  Remove keypad.
    1. 3.1  Unclip keypad on both sides using a suitable tool -arrows-  and lift it up until the electric plug connection is accessible.
    2. 3.2  Release and disconnect electric plug connection and remove keypad.
      G16225913Courtesy of PORSCHE CARS NORTH AMERICA, INC.

      Removing keypad
