Removing Heat Shield For Turbocharger
WARNING: This page is about a different variant/trim than selected.
- Remove heat shield for turbocharger -3-
.
- 1.1 Unclip lines for the oxygen sensors -4 and 5-
from the clips -6-
on the heat shield.
- 1.2 Loosen and unscrew nuts -1 and 2-
.
- 1.3 Remove heat shield -3-
.
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
|
Heat shield on turbocharger
