Removing Heat Shield For Rear Bumper

  1. Remove heat shield for rear bumper.
    1. 1.1 Loosen and unscrew nuts -1-  and screw -2-  .
    2. 1.2 Remove heat shield for rear bumper -3-  .
    G15877556Courtesy of PORSCHE CARS NORTH AMERICA, INC.

    Heat shield for rear bumper, left
