Technical Values

Location Descri... Type Basic value Tolerance 1 Tolerance 2
Screws on PCM display and operator control unit Item 2 Tightening torque 5.6 Nm (4.1 ftlb.)
G15875654Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Screws on PCM display and operator control unit
