Removing Air-Cleaner Element

Information

• The number of screws on the air-cleaner element can vary depending on engine type.
• The procedure for removing and installing is essentially the same.

1. Remove air-cleaner element -1-  .

   Courtesy of PORSCHE CARS NORTH AMERICA, INC.

   Air-cleaner element (shown on V6 monoturbo)

   1. 1.1  Loosen and unscrew screws -2-  .
   2. 1.2  Open clips -3-  using a suitable tool.
   3. 1.3  Remove air-cleaner element -1-  .
   4. 1.4  Clean the air cleaner housing.
