Removing Standard Tailpipe

WARNING: This page is about a different variant/trim than selected.
CAUTION: Hot components
  • Risk of burns

    → Let hot components cool down.

    → Wear personal protective gear.

  1. Remove standard tailpipe -1-  .
G15241466Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Standard tailpipe

  1. 1.1 Mark installation position of the tailpipe.
  2. 1.2 Loosen screw on clamp -3-  .
  3. 1.3 Pull standard tailpipe -1-  off the rear silencer -2-  .
