Subsequent Work

WARNING: This page is about a different variant/trim than selected.

Install new crankshaft sealing ring.
> Removing and installing crankshaft sealing ring
Install air-conditioning compressor bracket -5- .

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Air-conditioning compressor bracket
1. 2.1 Replace screws on air-conditioning compressor bracket.
2. 2.2 Position air-conditioning compressor bracket -5- .
3. 2.3 Fit and tighten new screws for air-conditioning compressor bracket -4- .
  > Tightening torque 23 Nm (17 ftlb.)
4. 2.4 Install tensioning roller -3- .
  1. 2.4.1 Position tensioning roller -3- .
  2. 2.4.2 Fit and tighten screw on tensioning roller -2- .
    > Tightening torque 25 Nm (18.4 ftlb.) (18.4 ftlb.)
  3. 2.4.3 Fit dust boot -1- .
Install air-conditioning compressor.
> Removing and installing air conditioning compressor
Install vibration damper.
> Removing and installing crankshaft vibration damper
Install oil guide housing.
> Removing and installing oil guide housing (V6 Turbo)
