Installing Front Window Channel Seal

Information

Make sure that the front window channel seal is fitted correctly during installation.

1. Align front window channel seal with the B-pillar trim.
2. Fit front window channel seal on the flange and press it on, starting at the front.
3. Press on front section of front window channel seal -1-  at the front edge of the door -2-  .

   Courtesy of PORSCHE CARS NORTH AMERICA, INC.

   Front edge of door
