Technical Values
WARNING: This page is about a different variant/trim than selected.
| Location |
Des... |
Type |
Basic val... |
Toleranc... |
Toleranc... |
| Brake booster to pedals |
Hexagon nut, M8 |
Tightening torque |
23 Nm (17 ftlb.) |
+ 2 Nm (1.5 ftlb.) |
| Pedals to body |
Item 2: Hexagon-head bolt, M8 x 35 |
Tightening torque |
23 Nm (17 ftlb.) |
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Screws securing pedals to body |
