Installing Upper Trailing Arm
WARNING: This page is about a different variant/trim than selected.
- Installation is performed in reverse order. Fit according to the previously applied markings -arrows-
.
Trailing arm to body: > Initial tightening 50 Nm (37 ftlb.)
> Final tightening + 120°
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
|
Marking upper trailing arm
