Adjusting rear-axle camber

  1. Turn the camber eccentric -B-  as required after loosening the lock nut -A-  .

    Then tighten the lock nut -A-  on the camber eccentric -B-  . Tightening torque 95 Nm (70 ftlb.)

    G11984587

    Rear-axle camber eccentric
