Trailer hitch maintenance: Checking function
WARNING: This page is about a different car, the 2016 Porsche Macan and 2015 Porsche Macan. However, it is still accessible from the selected car via links, so may be relevant.
Information
The function test on the electrical components of the trailer hitch can be performed using a trailer with no faults in the wiring and lights or using the Trailer Socket Tester WE 1439 . The procedure for testing using the Trailer Socket Tester WE 1439 is described below.
The Trailer Socket Tester WE 1439 can only be used to test 13-pin plug sockets. An adapter is required for testing 7-pin sockets.
Thermal cut-off can occur on the Trailer Socket Tester WE 1439 as a result of the build-up of heat.
