Removing Rear Wheel Housing Liner

WARNING: This page is about a different car, the 2018 Porsche Macan. However, it is still accessible from the selected car via links, so may be relevant.

Information:

The number of fastening screws, fixing clips, plug connections, holders and trim panels can vary depending on equipment .
The illustrations for removing and installing the drive mechanism are shown only on one equipment variant and may differ from the actual equipment variant .
Some steps must be carried out automatically .
Some of the repair illustrations show only one side of the vehicle .

Unscrew fastening screws -2 -.
Unscrew and remove fastening nuts -1 -.
Loosen and remove wheel housing liner -3 -.

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Rear right wheel housing liner
