74 Seat Cushions, Seat Covers -- (95B) MACAN
>>
WM 740819 Removing And Installing Front Seat-Surface Extension (Except MACAN Sport Edition)
>>
Technical Values
Technical Values
Location
Description
Type
Basic value
Tolerance 1
Tolerance 2
Fastening screw securing seat-surface extension to seat
Item 2
Tightening torque
7.5 Nm (5.5 ftlb.)
+/-0.5 Nm (+/-0.5 ftlb.)
