Preliminary Work For Relay Carrier In Engine Compartment

Fig 1: Identifying Engine Compartment Relay Carrier Position

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

1. Relay carrier in engine compartment
2. Relay carrier under passenger's seat

1. Move front lid to service position. → 552213 SECURING LID (SERVICE POSITION)
2. Disconnect lid seal on the right side. → REMOVING FRONT LID SEAL
3. Remove right cowl panel cover. → REMOVING COWL PANEL COVER
