Removing Secondary Air Valve

  1. Loosen secondary-air hoses -3-  .
    1. Secondary-air pipe
    2. Holder with clamp
    3. Clip
      4. Fig 1: Identifying Secondary-Air Hoses
      G09806095Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  2. Remove screw -2-  and carefully pull secondary air valve -1A, 1B or 1C-  out of the cylinder head.
    Fig 2: Installation Positions Of Secondary Air Valves
    G09806093Courtesy of PORSCHE CARS NORTH AMERICA, INC.
