Installing Front Ashtray

  1. Place front ashtray in installation position.
  2. Tighten fastening screws to the specified tightening torque Tightening torque 2.5 Nm +/-0.5 Nm (+/-0.5 ftlb.)  until secure.
    Fig 1: Securing Front Ashtray
    G09811637Courtesy of PORSCHE CARS NORTH AMERICA, INC.
