Preparing Rear-End Well (Re-Installing Well)

NOTE: Possible adhesion problems when bonding body parts
  • Several applications of primer can result in adhesion problems during bonding.

→ prime-coated spare parts must not be primed again before installation

→ only apply activator to prime-coated spare parts.

Information

  1. Activate the bonding area.
    1. 1.1. Apply activator -h3-  to the prime-coated surface.
      Fig 1: Applying Activator
      G09809807Courtesy of PORSCHE CARS NORTH AMERICA, INC.
