Creating Pattern Imprint

Tool box: Interior repairs system B1 WE 1355

1. Clean surface of the structural area to be copied using "Plastcleaner" and dry with warm air (approx. 60°C).
   Fig 1: Cleaning Surface

   Courtesy of PORSCHE CARS NORTH AMERICA, INC.
2. Evenly apply the "Moldmaker" 2-component material to the surface using the mixing tube and mixing gun.
3. Spread out the compound into a thin layer (approx. 2 - 3 mm) using a spatula.
   Fig 2: Creating Pattern Imprint

   Courtesy of PORSCHE CARS NORTH AMERICA, INC.
4. Leave pattern imprint to cure for 10 - 15 min.
5. Carefully remove pattern imprint and clean the surface using "Plastcleaner".
   Fig 3: Removing Pattern Imprint

   Courtesy of PORSCHE CARS NORTH AMERICA, INC.

   The pattern imprint can be re-used numerous times.

   The pattern imprint will not leave behind any undesirable marks and can therefore be used anywhere.
