Removing C-Pillar Tweeter

NOTE: Voltage peaks
  • Risk of damage to load or to the control unit

→ Remove the ignition key and switch off load before disconnecting or removing load.

  1. Unscrew the three fastening screws -1-  on the tweeter and remove the tweeter.
    Fig 1: Removing Tweeter In C-Pillar
    G09813821Courtesy of PORSCHE CARS NORTH AMERICA, INC.
